XCMG New QY25K-II Truck Crane

Dimension

Unit

QY25K-II

Overall length

mm

12650

Overall width

mm

2500

Overall height

mm

3380/3290

Weight

Total weight in travel

kg

29400

Front axle load

kg

6200

Rear axle load

kg

23200

Power

Engine model

WD615.329SC8DK280Q3

Engine rated power

kW/(r/min)

213/2200206/2200

Engine rated torque

N.m/(r/min)

1160/1100-16001112/1400

Travel

Max. travel speed

km/h

75

Min. turning diameter

mm

21500

Min. ground clearance

mm

275

Approach angle

°

16

Departure angle

°

13

Max. grade ability

%

30

Fuel consumption for 100km

L

37

Main performance

Max. rated total lifting capacity

t

25

Min. rated working radius

m

3

Turning radius at turntable tail

mm

3065

Max. lifting torque

KN.m

961

Base boom

m

10.8

Fully extended boom

m

34.2

Fully extended boom+jib

m

42.3
